JY-M12-2.87FY-12MP-1/2

JY-M12-2.87FY-12MP-1/2

Get A Quote

Online customer service
Factory guarantee
Ontime delivery

Model Number	JY-M12-2.87FY-12MP-1/2
Resolution	12MP
Image format	1/2"
Focal Length	2.8mm/2.87mm/3mm
Aperture	F2.8
Mount	M12*P0.5
Field Angle	120°
Total Track Length (TTL)	14.5mm
Sensor	IMX586
Type	low distortion lens
Application	CCTV lens
