JY-C-20M-10MP-2/3F2.8
JY-C-20M-10MP-2/3F2.8
- Online customer service
- Factory guarantee
- Ontime delivery
| Resolution | 10 MegaPixel | |||
| Image format | 2/3" | |||
| Focal length | 20mm | |||
| Aperture | F2.8±10% | |||
| Mount | C | |||
| Field Angle | D | 28.6° | ||
| H | 23.33° | |||
| V | 17.35° | |||
| M.O.D. | 20mm | |||
| Distortion | -0.60% | |||
| Dimension | Φ29×25.85mm | |||
| Flange BFL | 17.526mm | |||
| Back focal length | 13.45～15.48mm (in air) | |||
| MBF | <13.526mm (in air) | |||
| Operation | Focus | Manual | ||
| Zoom | / | |||
| Iris | Manual | |||
| Lens Material | Aluminum+9G | |||
| Weight | 30g | |||
| (Operating Temperature) | .-30℃~+80℃ | |||
| Material | Aluminum+9G | |||
